Remote Gas Leak Detector 460g Weight 30m Detection Distance 5ppm.m Sensitivity
Product Description:
Remote Gas Leak Detector is a gas detection equipment specially designed to remotely detect methane, as well as other gas mixtures containing methane (natural gas or similar gases).
It allows to quickly and safely find the point of gas leakage by pointing the laser beam at the studied area.
Features:
◇ High sensitivity, no other gas interference.
◇ Compact, small, lightweight, easy to operate and maintenance free.
◇ It detect methane in long distance, even through glass.
◇ Just respond to isolated strong absorption line of methane molecule that avoid to be interfered by other gas ingredients.
◇ High sensitivity and very short response time(≤100ms)
◇ It can be widely used for detecting leak of natural gas transferring pipe, environment of natural gas station and concentration of coal mine gas.
Technical Parameters:
| Parameters | Values |
| Principle | TDLAS |
| Detect Object | Methane(CH4) |
| EX proof safety | Exib IIC T4 Gb |
| Operating Temperature | -25℃ To +50℃ |
| Weight | 460g |
| Sensitivity | 5ppm.m |
| Detection Distance | 30m |
| Protection Level | IP66 |
| Response Time | Less Than100ms |
| Operating Humidity | 95%RH (non-condensing) |
| Detection Range | 0-100000ppm.m |
Applications:
Laser Methane Detectors for natural gas leak detection remote monitoring of elevated methane gas concentrations in ambient air.
It is specifically designed for the constant scanning and monitoring of mission-critical areas such as compressor stations, gas tanks, storage facilities, tank farms, gas stations, LNG Terminals, city gates and wellheads.
